5-Pack Common Mode Inductor 14×9×5mm 2mH 5A Ferrite Coil
5-Pack Common Mode Inductor 14×9×5mm 2mH 5A Ferrite Coil
5-Pack Common Mode Inductor – 14×9×5mm | 2mH | 5A | Ferrite Core
Keep your circuits clean and your electronics running smoothly with these high-quality common mode inductors. Wound on a premium ferrite magnetic ring core, each coil is engineered to suppress high-frequency electromagnetic interference (EMI) and ensure stable power filtering in a wide range of electronic applications. Ideal for DIY electronics, PCB design, power supplies, and general circuit-building projects.
Key Specifications
- Quantity: 5 pieces per pack
- Core Material: High-quality ferrite magnetic ring
- Dimensions: 14 × 9 × 5 mm
- Inductance: 2 mH
- Rated Current: 5 A
- Wire Diameter: 0.7 mm
- Power Rating: 0.7 W
Why Choose These Common Mode Inductors?
- Effective EMI Suppression: The ferrite toroidal core efficiently attenuates common mode noise and high-frequency interference, protecting sensitive downstream components.
- Compact Form Factor: At just 14×9×5mm, these inductors fit neatly into space-constrained PCB layouts without sacrificing performance.
- Reliable Power Filtering: Rated at 5A continuous current, making them suitable for power supply lines, motor drives, and switching regulators.
- Versatile Applications: Compatible with audio equipment, switching power supplies, LED drivers, inverters, and general electronic circuits.
- Great Value Pack: Five inductors per order so you always have spares on hand for prototyping or batch builds.
Package Contents
- 5 × Common Mode Inductor (14×9×5mm, 2mH, 5A)
Made in Mainland China.
Related Products You May Like
- 10-Pack Waterproof Cable Glands PG7 PG9 Nylon Connectors
- 10-Pack Rubber Strain Relief Cord Boot Protectors 4.6–6mm
- 25-in-1 Precision Magnetic Screwdriver Set | Pro Repair Kit
Learn more: OSHA on personal protective equipment
Frequently Asked Questions
Q: What is a common mode inductor and what does it do in a circuit?
A: A common mode inductor (also called a common mode choke) is a dual-winding inductor wound on a shared ferrite toroidal core. It presents high impedance to common mode noise — signals that appear simultaneously and in-phase on both lines — while passing differential (normal) signals with minimal loss. This makes it ideal for EMI suppression and power line filtering in switching power supplies, motor controllers, and audio circuits.
Q: What applications are these 2mH 5A ferrite inductors suitable for?
A: These common mode inductors are well-suited for a wide range of applications including switching power supplies (SMPS), LED driver circuits, DC-DC converters, inverters, audio equipment, motor drive boards, and general PCB power filtering. The 5A current rating and compact 14×9×5mm size make them a practical choice for both hobbyist projects and professional electronic designs.
Q: How do I install or solder these inductors onto a PCB?
A: These are through-hole style inductors. Simply insert the leads through the appropriate holes on your PCB, ensure correct orientation per your circuit schematic, and solder the leads on the underside. Trim any excess lead length after soldering. Always refer to your circuit design guidelines for proper placement and spacing.
