AFC2000 / AFR2000 + AL2000 G1/4 Air Source Treatment Unit
Keep your pneumatic tools and air compressor systems running cleanly and efficiently with this AFC2000/AFR2000 + AL2000 combination air source treatment unit. Featuring a G1/4 (PT1/4) port, this compact assembly integrates an air filter, pressure regulator, and lubricator (FRL unit) into one streamlined component — removing moisture, oil contaminants, and particulates from compressed air while maintaining precise, adjustable output pressure.
Key Features
- 3-in-1 FRL Combination: Filter, regulator, and lubricator combined for comprehensive air source treatment in a single compact unit.
- Effective Oil & Water Separation: Removes moisture and oil aerosols from compressed air lines to protect downstream tools and equipment.
- Wide Adjustable Pressure Range: Regulate output pressure from 0 to 0.95 MPa (135 PSI / 9.5 bar) to suit a variety of pneumatic applications.
- High Pressure Resistance: Withstands up to 1.5 MPa (217 PSI) for safe, reliable operation under demanding conditions.
- Generous Cup Capacity: Water filter cup holds 15CC; water cup capacity is 25CC — minimizing maintenance intervals.
- Broad Temperature Tolerance: Operates effectively between 5°C and 60°C for workshop and industrial environments.
- Durable Construction: Built from metal and plastic for a robust, long-lasting build that stands up to daily workshop use.
- Universal G1/4 (PT1/4) Port: Compatible with standard pneumatic fittings and air compressor lines.
Specifications
| Models | AFC2000 / AFR2000 + AL2000 |
| Port Size | PT1/4 (G1/4) |
| Working Medium | Air |
| Max. Pressure | 9.9 kgf/cm² |
| Max Adjustable Pressure Range | 0.95 MPa / 135 PSI / 9.5 bar |
| Pressure Resistance | 1.5 MPa / 217 PSI / 1.5–8.5 bar |
| Temperature Range | 5°C – 60°C |
| Water Filter Cup Capacity | 15CC |
| Water Cup Capacity | 25CC |
| Material | Metal & Plastic |
| Country of Origin | Made in Mainland China |
What's in the Box
- 1 × AFC2000/AFR2000 + AL2000 Air Filter Regulator & Lubricator Unit
Related Products You May Like
- 25-in-1 Precision Magnetic Screwdriver Set | Pro Repair Kit
- 10-Pack Waterproof Cable Glands PG7 PG9 Nylon Connectors
- 34-Compartment Double-Sided Hardware Storage Box & Dividers
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: What does the AFC2000/AFR2000 + AL2000 FRL unit do?
A: This combination unit performs three essential functions for compressed air systems: the filter (AFC2000/AFR2000) removes water droplets, oil aerosols, and particulates from the air line; the regulator allows you to set and maintain a precise, stable output pressure; and the lubricator (AL2000) introduces a fine mist of oil to protect downstream pneumatic tools and cylinders from wear.
Q: What port size does this air filter regulator use?
A: This unit features a PT1/4 (G1/4) port size, which is compatible with standard pneumatic fittings and most common air compressor line connections used in workshops and industrial settings.
Q: What is the maximum adjustable pressure for this regulator?
A: The maximum adjustable output pressure is 0.95 MPa (approximately 135 PSI or 9.5 bar). The unit can withstand inlet pressures up to 1.5 MPa (217 PSI), making it suitable for a wide range of pneumatic tool and automation applications.
Q: How often should I drain the water filter cup?
A: Drainage frequency depends on the humidity of your environment and how heavily the compressor is used. It is good practice to check and drain the water filter cup (15CC capacity) regularly — ideally before each use session — to maintain clean, dry air delivery and protect your pneumatic equipment.
